How to identify your Moen pulldown kitchen faucet spray wand by detailed information and pictures. It is recommended to first identify your faucet model number.

This guide will explain how to identify a Moen kitchen faucet's pulldown spray wand. In keeping up with current styles and trends, existing models are occasionally updated. Although the faucet may look the same and have the same model number, the spray wand may have changed.

Follow the steps below to help identify your spray wand.

Step 1: Type of Faucet?

How does your spray wand pull out from the faucet? This guide is designed for pulldown faucets. If you have a pullout faucet, click here to view the pullout wand chart.

Pulldown:

id pulldown spray wand- pulldown example.png

Pullout:

id pulldown spray wand- pullout example.png
Step 2: Type of Spray Wand?

1. What are the sprayer functions?

Stream, Spray and Pause

2. How many buttons/pads are there?

 identify pulldown wands- pads.png

3. What is the "GPM" (gallons per minute)?

This can be located on the face of the spray wand. Example: "1.5 GPM" or "2.2 GPM"

 identify pulldown wands- face.png
Step 3: Length of Spray Wand?

This step does not require removing the spray wand from the hose. All measurements listed below are taken with the spray wand in the retracted position, see image below.

Caution: We do not recommend unthreading the spray wand from the hose. The hose is designed to automatically retract inside the faucet body and could become difficult to extract.

identify pulldown wands- wand reach.png


Use the article, Faucet Finishes, to help determine your spray wand finish and which suffix to use.

40043

40043 wand.png

Finishes: CH, CSL

Features:

  • 1.5 GPM
  • Plastic
  • 3.35" Long
  • Nothing Written On Face Of Spray Wand
  • 0 Buttons/Pads
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

None- Face of spray wand rotates to change functions

40043 pad.png

Model Name/Model Number/Spray Wands Used:

Cleveland Faucet Group Baystone 42519 & CA42519

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 42082 and 40043
42082

42082 wand.png

Finishes: CH, CSL

Features:

  • 2.2 GPM
  • Plastic
  • 3.35" Long
  • Nothing Written On Face Of Spray Wand
  • 0 Buttons/Pads
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

None- Face of spray wand rotates to change functions

42082 pad.png

Model Name/Model Number/Spray Wands Used:

Cleveland Faucet Group Baystone 42519 & CA42519

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 42082 and 40043
100499

100499 wand.png

Finishes: CH, CSL, BL, SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

100499 pad.png

Model Name/Model Number/Spray Wands Used:

The following models listed were all sold in retail stores

Harlon 87499

  • Wand Numbers 100499, 162469 and 161150

Benton 87211

  • Wand Numbers 100499 and 162464

Lancaster CA87020

  • Wand Numbers 100499, 148256 and 162464

Solidad 87559 & CA87559

  • Wand Numbers 100499, 148256 and 164464

Boutique 87006 & CA87006

  • Wand Numbers 100499, 148256 and 162464

Anabelle 87003 & CA87003

  • Wand Numbers 100499, 148256 and 162464
114296 (Obsolete)

114296 wand.png

Finishes: CH, SL, CPR, S, W, V, CP

Features:

  • 2.2 GPM
  • Metal
  • 3.74" Long
  • "7590" Printed On Face Of Spray Wand
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

114296 pad.png

Model Name/Model Number/Spray Wands Used:

Aberdeen (sold through wholesale and plumbing distributors)

  • 7590 & 7592
    • Wand Numbers 114296, 134742 and 161149
  • CA7590 & CA7592
    • Never Used 114296 or 161149
    • Wand Number Used 134742

Woodmere (Sold through wholesale and plumbing distributors)

  • S728
    • Wand Numbers 114296, 134742
  • S7208
    • Never Used 114296
    • Wand Numbers Used 134742 and 161149
  • CAS7208
    • Never Used 114296
    • Wand Number Used 134742
  • 7615
    • Never Used 114296
    • Wand Number Used 161149
118298

118298 wand.png

Finishes: CH, CSL, SL, ORB, SRS

Features:

  • 2.2 GPM
  • Metal
  • 2.29" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

118298 pad.png

Model Name/Model Number/Spray Wands Used:

Woodmere Bar Faucets S628, S6208, CAS6208

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 118298 and 161153
130955

130955 wand.png

Finishes: CH, SL

Features:

  • 2.2 GPM
  • Plastic
  • 3.44" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

130955 pad.png

Model Name/Model Number/Spray Wands Used:

Triana 87555, 87556, CA87555

  • Sold in retail stores
  • Wand Number 130955
131380

131380 wand.png

Finishes: CH, SL, CSL, ORB, BL, SRS

Features:

  • 2.2 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

131380 pad.png

Model Name/Model Number/Spray Wands Used:

Arbor (Sold through wholesale and plumbing distributors)

  • Mechanical Faucets 7594 & CA7594
    • Wand Numbers 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Wand Numbers 163795, 131380, 161150 and 162469
  • Hands Free Wave Faucet 7594EW
    • Never Used 131380
    • Wand Number Used 161150 (or for SRS finish- 162469)
  • Smart Faucet 7594EV
    • Never Used 131380
    • Wand Number Used 194004
  • Bar Faucets 5995 & CA5995
    • Never Used 131380
    • Wand Numbers Used 161145, 160998 and 151189

Kleo CA87011

  • Sold in retail stores
  • Wand Numbers 131380, 162678 and 162469

Medora 7599 & CA7599

  • Sold through wholesale and plumbing distributors
  • Wand Number 131380
134414 (Obsolete)

134414 wand.png

Finishes: CH, SL, CSL

Features:

  • 2.2 GPM
  • Plastic
  • 3.76" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

134414 pad.png

Model Name/Model Number/Spray Wands Used:

Divine S758 & CAS758

  • Sold through wholesale and plumbing distributors
  • Wand Number 134414
134742

134742 wand.png

Finishes: CH, SL, CSL, V, W, CPR, ORB

Features:

  •  2.2 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

134742 pad.png

Model Name/Model Number/Spray Wands Used:

Woodmere (Sold through wholesale and plumbing distributors)

  • S728
    • Wand Numbers 114296 and 134742
  • S7208
    • Wand Numbers Used 134742 and 161149
  • CAS7208
    • Wand Number Used 134742
  • 7615
    • Never Used 134742
    • Wand Numbers Used 161149

Aberdeen (sold through wholesale and plumbing distributors)

  • 7590 & 7592
    • Wand Numbers 114296, 134742 and 161149
  • CA7590 & CA7592
    • Wand Number 134742
140244 (Obsolete)

140244 wand.png

Finishes: CH, CSL, BL, SRS

Features:

  • 2.2 GPM
  • Plastic
  • 3.36" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

140244 pad.png

Model Name/Model Number/Spray Wands Used:

Ascent S71708 & CAS71708

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 140244 and 161154
140246

140246 wand.png

Finishes: CH, CSL, BL, SRS

Features:

  • 2.2  GPM
  • Metal
  • Plastic
  • 2.29" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

140246 pad.png

Model Name/Model Number/Spray Wands Used:

Ascent Bar Faucets S61708 & CAS61708

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 140246 and 161152
140995

140995 wand.png

Finishes: CH, CSL

Features:

  • 2.2 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

140995 pad.png

Model Name/Model Number/Spray Wands Used:

Level 7175 & CA7175

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 140995 and 161148
148256 (Obsolete)

148256 wand.png

Finishes: CH, CSL, BL, SRS, BRB

Features:

  • 1.5 GPM
  • Metal
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

148256 pad.png

Model Name/Model Number/Spray Wands Used:

Lancaster CA87020

  • Sold in retail stores
  • Wand Numbers 100499, 148256 and 162464

Lindley CA87012

  • Sold in retail stores
  • Wand Numbers 162677, 148256 and 162470

Solidad (Sold in retail stores)

  • CA87559
    • Wand Numbers 100499, 148256 and 164464
  • 87559
    • Never Used 148256
    • Wand Number Used 100499

Boutique (Sold in retail stores)

  • CA87006
    • Wand Numbers 100499, 148256 and 162464
  • 87006
    • Never Used 148256
    • Wand Number Used 100499

Anabelle (Sold in retail stores)

  • CA87003
    • Wand Numbers 100499, 148256 and 162464
  • 87003
    • Never Used 148256
    • Wand Number Used 100499
151189

151189 wand.png

Finishes: CH, CSL, ORB, BL

Features:

  • 1.5 GPM
  • Had both plastic and metal versions
  • 2.28" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

151189 pad.png

Model Name/Model Number/Spray Wands Used:

Arbor (Sold through wholesale and plumbing distributors)

  • Bar Faucets 5995 & CA5995
    • Wand Numbers 161145, 160998 and 151189
  • Mechanical Faucets 7594 & CA7594
    • Never Used 151189
    • Wand Numbers Used 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Never Used 151189
    • Wand Numbers Used 163795, 131380, 161150 and 162469
  • Hands Free Wave Faucet 7594EW
    • Never Used 151189
    • Wand Numbers Used 161150 (or for SRS finish- 162469)
  • Smart Faucet 7594EV
    • Never Used 151189
    • Wand Number Used 194004
153977

153977 wand.png

Finishes: CH, CSL, ORB

Features:

  • 2.2 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

153977 pad.png

Model Name/Model Number/Spray Wands Used:

Brantford (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7185
    • Wand Numbers 153977, 161157 and 191005
  • Bar Faucet 5985
    • Never Used 153977
    • Wand Numbers Used 153980 and 161156
  • Hands Free Motionsense Faucet 7185E
    • Never Used 153977
    • Wand Numbers Used 179645 and 161157
  • Hands Free Wave Faucet 7185EW
    • Never Used 153977
    • Wand Number Used 179645
  • Smart Faucet 7185EV
    • Never Used 153977
    • Wand Number Used 194005
153980

153980 wand.png

Finishes: CH, CSL, ORB, SRS

Features:

  • 2.2 GPM
  • Metal
  • 2.42" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

153980 pad.png

Model Name/Model Number/Spray Wands Used:

Brantford (Sold through wholesale and plumbing distributors)

  • Bar Faucet 5985
    • Wand Numbers 153980 and 161156
  • Mechanical Faucet 7185
    • Never Used 153980
    • Wand Numbers Used 153977, 161157 and 191005
  • Hands Free Motionsense Faucet 7185E
    • Never Used 153980
    • Wand Numbers Used 179645 and 161157
  • Hands Free Wave Faucet 7185EW
    • Never Used 153980
    • Wand Number Used 179645
  • Smart Faucet 7185EV
    • Never Used 153980
    • Wand Number Used 194005
153984

153984 wand.png

Finishes: SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

153984 pad.png

Model Name/Model Number/Spray Wands Used:

Bayhill CA87094

  • Sold in retail stores
  • Wand Numbers 153984 and 162424

Delaney 87359E

  • Sold in retail stores
  • Wand Numbers 153984 and 173137
158918

158918 wand.png

Finishes: CH, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.36" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Power Clean Spray* and Pause

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

158918 pad.png

Model Name/Model Number/Spray Wands Used:

Haysfield (Sold in retail stores)

  • Mechanical Faucets 87879 & 87877
    • Wand Number 158918
  • Hands Free Motionsense Faucet 87350E
    • Never Used 158918
    • Wand Numbers Used 163795 and 162469
160998

160998 wand.png

Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 2.28" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Power Clean Spray* and Pause

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

160998 pad.png

Model Name/Model Number/Spray Wands Used:

Arbor (Sold through wholesale and plumbing distributors)

  • Bar Faucet 5995
    • Wand Numbers 161145, 160998 and 151189
  • Mechanical Faucets 7594 & CA7594
    • Never Used 160998
    • Wand Numbers Used 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Never Used 160998
    • Wand Numbers Used 163795, 131380, 161150 and 162469
  • Hands Free Wave Faucet 7594EW
    • Never Used 160998
    • Wands Numbers Used 161150 (or for SRS finish- 162469)
  • Smart Faucet 7594EV
    • Never Used 160998
    • Wand Number Used 194004
161145

161145 wand.png

Finishes: CH, CSL, ORB, BL

Features:

  • 1.5 GPM
  • Plastic
  • 2.28" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

161145 pad.png

Model Name/Model Number/Spray Wands Used:

Arbor (Sold through wholesale and plumbing distributors)

  • Bar Faucet 5995
    • Wand Numbers 161145, 160998 and 151189
  • Mechanical Faucets 7594 & CA7594
    • Never Used 161145
    • Wand Numbers Used 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Never Used 161145
    • Wand Numbers Used 163795, 131380, 161150 and 162469
  • Hands Free Wave Faucet 7594EW
    • Never Used 161145
    • Wand Numbers Used 161150 (or for SRS finish- 162469)
  • Smart Faucet 7594EV
    • Never Used 161145
    • Wand Number Used 194004
161148

161148 wand.png

Finishes: CH, CSL, MSRS, BL

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

161148 pad.png

Model Name/Model Number/Spray Wands Used:

Indi 87090

  • Sold in retail stores
  • Wand Number 161148

Level 7175 (Sold through wholesale and plumbing distributors)

  • 7175
    • Wand Numbers 140995 and 161148
  • CA7175
    • Never Used 161148
    • Wand Number Used 140995

Indi 87194

  • Sold in retail stores
  • Wand Number 161148
161149

161149 wand.png

Finishes: CH, CSL, SRS, ORB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

161149 pad.png

Model Name/Model Number/Spray Wands Used:

Woodmere (Sold through wholesale and plumbing distributors)

  • 7615
    • Wand Number Used 161149
  • S7208
    • Wand Numbers Used 134742 and 161149
  • S728
    • Never Used 161149
    • Wand Numbers Used 114296 and 134742
  • CAS7208
    • Never Used 161149
    • Wand Number Used 134742

Aberdeen (sold through wholesale and plumbing distributors)

  • 7590 & 7592
    • Wand Numbers 114296, 134742 and 161149
  • CA7590 & CA7592
    • Never Used 161149
    • Wand Number Used 134742
161150

161150 wand.png

Finishes: CH, CSL, ORB, BL

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

161150 pad.png

Model Name/Model Number/Spray Wands Used:

Harlon 87499

  • Sold in retail stores
  • Wand Numbers 100499, 162469 and 161150

Arbor (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7594 & CA7594
    • Wand Numbers 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Wand Numbers 163795, 131380, 161150 and 162469
  • Hands Free Wave Faucet 7594EW
    • Wands Used 161150 (or for SRS finish- 162469)
  • Smart Faucet 7594EV
    • Never Used 161150
    • Wand Number Used 194004
  • Bar Faucets 5995 & CA5995
    • Never Used 161150
    • Wand Numbers Used 161145, 160998 and 151189

Essie (Sold in retail stores)

  • Mechanical Spring Faucet 87814
    • Wand Numbers 162469 (or for CH finish- 161150)
  • Hands Free Wave Faucet 87014EW
    • Wand Numbers 162469 (or for CH finish- 161150)
  • Mechanical Faucet 87014
    • Never Used 161150
    • Wand Number Used 162469
161152

161152 wand.png

Finishes: CH, CSL, BL, SRS

Features:

  • 1.5 GPM
  • Metal
  • 2.29" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

161152 pad.png

Model Name/Model Number/Spray Wands Used:

Ascent (Sold through wholesale and plumbing distributors)

  • Bar Faucet S61708
    • Wand Numbers 140246 and 161152
  • Bar Faucet CAS61708
    • Never Used 161152
    • Wand Number Used 140246
161153

161153 wand.png

Finishes: CH, CSL, ORB, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 2.29" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

161153 pad.png

Model Name/Model Number/Spray Wands Used:

Woodmere Bar Faucets S628, S6208, CAS6208

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 118298 and 161153
161154

161154 wand.png

Finishes: CH, CSL, BL, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.36" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

161154 pad.png

Model Name/Model Number/Spray Wands Used:

Ascent S71708 & CAS71708

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 140244 and 161154
161156

161156 wand.png

Finishes: CH, CSL, ORB

Features:

  • 1.5 GPM
  • Plastic
  • 2.42" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

161156 pad.png

Model Name/Model Number/Spray Wands Used:

Brantford (Sold through wholesale and plumbing distributors)

  • Bar Faucet 5985
    • Wand Numbers 153980 and 161156
  • Mechanical Faucet 7185
    • Never Used 161156
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Hands Free Motionsense Faucet 7185E
    • Never Used 161156
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Hands Free Wave Faucet 7185EW
    • Never Used 161156
    • Wand Number Used 140246
161157

161157 wand.png

Finishes: CH, CSL, ORB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Power Clean Spray* and Pause

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

161157 pad.png

Model Name/Model Number/Spray Wands Used:

Brantford (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7185
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Hands Free Motionsense Faucet 7185E
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Bar Faucet 5985
    • Never Used 161157
    • Wand Numbers Used 153980 and 161156
  • Hands Free Wave  Faucet 7185EW
    • Never Used 161157
    • Wand Number Used 140246
162424

162424 wand.png

Finishes: BRB, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

162424 pad.png

Model Name/Model Number/Spray Wands Used:

Russo 87407

  • Sold in retail stores
  • Wand Number 162424

Bayhill CA87094

  • Sold in retail stores
  • Wand Numbers 153984 and 162424
162464

162464 wand.png

Finishes: CH, SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Power Clean Spray* and Pause

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

162464 pad.png

Model Name/Model Number/Spray Wands Used:

The following models listed were all sold in retail stores

Nellis 87794

  • Wand Number 162464

Kaden 87966

  • Wand Number 162464

Kipton 87910

  • Wand Number 162464

Benton 87211

  • Wand Numbers 100499 and 162464

Lancaster CA87020

  • Wand Numbers 100499, 148256 and 162464

Solidad

  • CA87559
    • Wand Numbers 100499, 148256 and 164464
  • 87559
    • Never Used 162464
    • Wand Number Used 100499

Boutique

  • CA87006
    • Wand Numbers 100499, 148256 and 162464
  • 87006
    • Never Used 162464
    • Wand Number Used 100499

Anabelle

  • CA87003
    • Wand Numbers 100499, 148256 and 162464
  • 87003
    • Never Used 148256
    • Wand Number Used 100499

Ridgedale 87340E

  • Wand Number 162464
162469

162469 wand.png

Finishes: CH, BL, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Power Clean Spray* and Pause

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

162469 pad.png

Model Name/Model Number/Spray Wands Used:

Essie (Sold in retail stores)

  • Mechanical Faucet 87014
    • Wand Number 162469
  • Mechanical Spring Faucet 87814
    • Wand Numbers 162469 (or for CH finish- 161150)
  • Hands Free Wave Faucet 87014EW
    • Wand Numbers 162469 (or for CH finish- 161150)

Georgene (Sold in retail stores)

  • Mechanical Faucet 87912
    • Wand Number 162469
  • Hands Free Wave Faucet
    • Wand Number 162469

Lucira 87699

  • Sold in retail stores
  • Wand Number 162469

Lodi 181630

  • Sold in retail stores
  • Wand Number 162469

Kelsa 180112

  • Sold in retail stores
  • Wand Number 162469

Harlon 87499

  • Sold in retail stores
  • Wand Numbers 100499, Wand Numbers 162469 (or for CH finish- 161150)

Arbor (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7594 & CA7594
    • Wand Numbers 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Wand Numbers 163795, 131380, 161150 and 162469
  • Bar Faucets 5995 & CA5995
    • Never Used 162469
    • Wand Numbers Used 161145, 160998 and 151189
  • Hands Free Wave Faucet 7594EW
    • Never Used 131380
    • Wand Numbers Used 161150 (or for SRS finish- 162469)
  • Smart Faucet 7594EV
    • Never Used 131380
    • Wand Number Used 194004

Kleo CA87011

  • Sold in retail stores
  • Wand Numbers Used 131380, 162678 and 162469

Haysfield (Sold in retail stores)

  • Hands Free Motionsense Faucet 87350E
    • Wand Numbers 163795 and 162469
  • Mechanical Faucets 87879 & 87877
    • Never Used 162469
    • Wand Number Used 158918

Lainie 21689

  • Sold in retail stores
  • Wand Number 162469

Birchfield (Sold in retail stores)

  • Hands Free Wave Faucet 87250EW
    • Wand Number 162469
162470

162470 wand.png

Finishes: SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Power Clean Spray* and Pause

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

162470 pad.png

Model Name/Model Number/Spray Wands Used:

Glenshire 87731

  • Sold in retail stores
  • Wand Number 162470

Lindley CA87012

  • Sold in retail stores
  • Wand Numbers 162677, 148256 and 162470
162476

162476 wand.png

Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 2.3" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

162476 pad.png

Model Name/Model Number/Spray Wands Used:

Terrace CA87055

  • Sold in retail stores
  • Wand Numbers 168949 and 162476
162677

162677 wand.png

Finishes: CSL, BRB, SRS

Features:

  • 2.2 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

162677 pad.png

Model Name/Model Number/Spray Wands Used:

Lindley CA87012

  • Sold in retail stores
  • Wand Numbers 162677, 148256 and 162470
162678

162678 wand.png

Finishes: CSL, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

162678 pad.png

Model Name/Model Number/Spray Wands Used:

Kleo CA87011

  • Sold in retail stores
  • Wand Numbers 131380, 162678 and 162469
162716

162716 wand.png

Finishes: CH, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.78" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

162716 pad.png

Model Name/Model Number/Spray Wands Used:

Kiran 87599

  • Sold in retail stores
  • Wand Number 162716

Kiran 202739

  • Sold in retail stores
  • Wand Number 162716

Cleveland Faucet Group

Slate 76162

  • Sold through wholesale and plumbing distributors
  • Wand Number 162716 & 199817
163795 (Obsolete)

163795 wand.png

Finishes: CH, ORB, SRS

Features:

  • 2.0 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Spray and Pause

Button/Pad:

(Rubber)

163795 pad.png

Model Name/Model Number/Spray Wands Used:

Haysfield (Sold in retail stores)

  • Hands Free Motionsense Faucet 87350E
    • Wand Numbers 163795 and 162469
  • Mechanical Faucet 87879 & 87877
    • Never Used 162469
    • Wand Number Used 158918

Arbor (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7594 & CA7594
    • Wand Numbers 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Wand Numbers 163795, 131380, 161150 and 162469
  • Bar Faucets 5995 & CA5995
    • Never Used 163795
    • Wand Numbers Used 161145, 160998 and 151189
  • Hands Free Wave Faucet 7594EW
    • Never Used 163795
    • Wand Numbers Used 161150 (or for SRS finish- 162469)
  • Smart Faucet 7594EV
    • Never Used 163795
    • Wand Number Used 194004
168492

168492 wand.png

Finishes: CH, SRS, BL, BG

Features:

  • 1.5 GPM
  • Plastic
  • " Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Plastic)

168492 pad.png

Model Name/Model Number/Spray Wands Used:

Align (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7565
    • Wand Number 168492
  • Hands Free Motionsense Faucet 7565E
    • Wand Number 168492
  • Smart Faucet 7565EV
    • Wand Number 168492
  • Mechanical Spring Faucet 5923
    • Never Used 168492
    • Wand Number Used 173816
  • Hands Free Wave Spring Faucet 5923EW
    • Never Used 168492
    • Wand Number Used 173816

Cia (Sold through wholesale and plumbing distributors)

  • Hands Free Wave Faucet 7622EW
    • Wand Number 168492
  • Smart Faucet 7622EV
    • Wand Number 168492
168500

168500 wand.png

Finishes: Black (Concealed Spray Wand)

Features:

  • 1.5 GPM
  • Plastic
  • " Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Plastic)

168500 pad.png

Model Name/Model Number/Spray Wands Used:

Nio (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet S75005
    • Wand Number 168500
  • Smart Faucet S75005EV
    • Wand Number S168500

Sto (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet S72308
    • Wand Number 168500
  • Hands Free Motionsense Faucet S72308E
    • Wand Number 168500
  • Smart Faucet S72308EV
    • Wand Number 168500
168949

168949 wand.png

Finishes: CH

Features:

  • 1.5 GPM
  • Plastic
  • 2.3" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

162476 pad.png

Model Name/Model Number/Spray Wands Used:

Terrace CA87055

  • Sold in retail stores
  • Wand Numbers 168949 and 162476
173137

173137 wand.png

Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

173137 pad.png

Model Name/Model Number/Spray Wands Used:

Conneaut 87801

  • Sold in retail stores
  • Wand Number 173137

Zabelle 87126

  • Sold in retail stores
  • Wand Number 173137

Russo 87407

  • Sold in retail stores
  • Wand Number 162424 and 173137

Delaney 87359E

  • Sold in retail stores
  • Wand Numbers 153984 and 173137
173816

173816 wand.png

Finishes: CH, SRS, BL

Features:

  • 1.5 GPM
  • Plastic
  • 3.24" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

173816 pad.png

Model Name/Model Number/Spray Wands Used:

Align (Sold through wholesale and plumbing distributors)

  • Mechanical Spring Faucet 5923
    • Wand Number 173816
  • Hands Free Wave Spring Faucet 5923EW
    • Wand Number 173816
  • Hands Free Motionsense Faucet 7565E
    • Never used 173816
    • Wand Number Used 168492
  • Mechanical Faucet 7565
    • Never Used 173816
    • Wand Number Used 168492

Kessen 87023

  • Sold in retail stores
  • Wand Number 173816

Nori 87066

  • Sold in retail stores
  • Wand Number 173816

Nori 87897

  • Sold in retail stores
  • Wand Number 173816
174949

174949 wand.png

Finishes: MSRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.78" Long
  • 1 Button/Pad
  • 3 Sprayer Functions: Stream, Power Clean Spray* and Pause

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

174949 pad.png

Model Name/Model Number/Spray Wands Used:

Hensley 87024

  • Sold in retail stores
  • Wand Number 174949
175392

175392 wand.png

Finishes: CH, CSL

Features:

  • 1.5 GPM
  • Plastic
  • 3.35" Long
  • 0 Buttons/Pads
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

None- Face of spray wand rotates to change functions

175392 pad.png

Model Name/Model Number/Spray Wands Used:

Cleveland Faucet Group Edgestone 46201

  • Sold through wholesale and plumbing distributors
  • Wand Number 175392
175984 (Obsolete)

175984 wand.png

Finishes: CH, SRS, ORB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

175984 pad.png

Model Name/Model Number/Spray Wands Used:

Notch (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 9124
    • Wand Numbers 175984 and 191006
  • Bar Faucet 6124
    • Never Used 175984
    • Wand Number Used 175989
175989

175989 wand.png

Finishes: CH, ORB, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 7.42" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

175989 pad.png

Model Name/Model Number/Spray Wands Used:

Notch (Sold through wholesale and plumbing distributors)

  • Bar Faucet 6124
    • Wand Number 175989
  • Mechanical Faucet 9124
    • Never Used 175989
    • Wand Numbers Used 175984 and 191006
176263

176263 wand.png

Finishes: Black (Concealed Spray Wand)

Features:

  • 1.5 GPM
  • Plastic
  • 3.22" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

176263 pad.png

Model Name/Model Number/Spray Wands Used:

Etch (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet S72608
    • Wand Number 176263
  • Bar Faucet S62608
    • Never Used 176263
    • Wand Number Used 176264
176264

176264 wand.png

Finishes: CH, SRS

Features:

  • 1.5 GPM
  • Metal
  • 2.42" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

176264 pad.png

Model Name/Model Number/Spray Wands Used:

Etch (Sold through wholesale and plumbing distributors)

  • Bar Faucet S62608
    • Wand Number 176264
  • Mechanical Faucet S72608
    • Never Used 176264
    • Wand Number Used 176263
179572

179572 wand.png

Finishes: MSRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.23" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

179572 pad.png

Model Name/Model Number/Spray Wands Used:

Wellsley 87022

  • Sold in retail stores
  • Wand Number 179572
179574

179574 wand.png

Finishes: CH, SRS, BL

Features:

  • 1.5 GPM
  • Plastic
  • 3.24" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

179574 pad.png

Model Name/Model Number/Spray Wands Used:

Edwyn 87807, 87028, 87128

  • Sold in retail stores
  • Wand Number 179574

Irvine 87355

  • Sold in retail stores
  • Wand Number 179574

Tarvo 87096

  • Sold in retail stores
  • Wand Number 179574

Riley (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7402
    • Wand Number 179574
  • Hands Free Wave Faucet 7402EW
    • Wand Number 179574

Benson 87304

  • Sold in retail stores
  • Wand Number 179574

Gene 87438

  • Sold in retail stores
  • Wand Number 179574

Arlo 87087EW

  • Sold in retail stores
  • Wand Number 179574

Sperry 87696EW

  • Sold in retail stores
  • Wand Number 179574
179645 (Obsolete)

179645 wand.png

Finishes: CH, ORB, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

179645 pad.png

Model Name/Model Number/Spray Wands Used:

Brantford (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7185
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Hands Free Motionsense Faucet 7185E
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Hands Free Wave Faucet 7185EW
    • Never Used 179645
    • Wand Number Used 140246
179981

179981 wand.png

Finishes: SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.28" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

179981 pad.png

Model Name/Model Number/Wands Spray Used:

Bridgestone 87038

  • Sold in retail stores
  • Wand Number 179981
179983

179983 wand.png

Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

179983 pad.png

Model Name/Model Number/Spray Wands Used:

Kendall 87032

  • Sold in retail stores
  • Wand Number 179983
180059

180059 wand.png

Finishes: CH, SRS, BL

Features:

  • 1.0 GPM
  • Plastic
  • 3.12" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Plastic)

180059 pad.png

Model Name/Model Number/Spray Wands Used:

Service Kit Only (not packaged with a faucet)
184431

184431 wand.png

Finishes: CH, SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.24" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Noell 87791

  • Sold in retail stores
  • Wand Number 184431
185137


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.24" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Lizzy 87519

  • Sold in retail stores
  • Wand Number 185137
186860


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.24" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Caris 87402

  • Sold in retail stores
  • Wand Number 186860
186903


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.24" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Fieldstone 87808

  • Sold in retail stores
  • Wand Number 186903
187728


Finishes: CH, SRS, BL, BG

Features:

  • 1.5 GPM
  • 3.63" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Reza 87228

  • Sold in retail stores
  • Wand Number 187728

Sleek (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7864
    • Wand Numbers 187728 and 198279
  • Hands Free Wave Faucet 7864EW
    • Wand Number 187728
  • Mechanical Spring Faucet 5925
    • Never Used 187728
    • Wand Number Used 198279
  • Smart Faucet 7864EV
    • Never Used 187728
    • Wand Number Used 198279

Cadia (Sold in retail stores)

  • Hands Free Wave Facuet 87869EW
    • Wand Numbers 187728
188029


Finishes: CH, SRS, BL

Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Genta (Sold through wholesale and plumbing distributors)

  • Mecahnical Faucet 7882
    • Wand Number 188029
  • Hands Free Wave Faucet Genta LX 7882EW
    • Wand Number 188029
189302


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Button/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Buttons/Pads:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Tullis 87235

  • Sold in retail stores
  • Wand Number 189302
189304


Finishes: CH, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Button/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Hadley 87245

  • Sold in retail stores
  • Wand Number 189304
190443


Finishes: CH, SRS, BL

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Button/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Springvale 87998

  • Sold in retail stores
  • Wand Number 190443

Haelyn 87627

  • Sold in retail stores
  • Wand Number 190443

Reza 199748

  • Sold in retail stores
  • Wand Number 190443
190443EI


Finishes: CH, SRS, BL

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Button/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*Self Powered LED

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Haelyn 87627EI

  • Sold in retail stores
  • Wand Number 190443EI
190504


Finishes: CH, SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Button/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Coretta 87997

  • Sold in retail stores
  • Wand Number 190504


191004


Finishes: CH, ORB, BL, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Arbor (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7594 & CA7594
    • Wand Numbers 131380, 161150, 162469 and 191004
  • Hands Free Motionsense Faucet 7594E
    • Wand Numbers 163795, 131380, 161150 and 162469
  • Smart Faucet 7594EV
    • Wands Used 194004
  • Bar Faucets 5995 & CA5995
    • Never Used 191004
    • Wand Numbers Used 161145, 160998 and 151189
  • Hands Free Wave Faucet 7594EW
    • Never Used 191004
    • Wand Numbers Used 161150 (or for SRS finish- 162469)

Birchfield 87205

  • Sold in retail stores
  • Wand Number 191004

Leesi 87448

  • Sold in retail stores
  • Wand Number 191004

Mali 87561

  • Sold in retail stores
  • Wand Number 191004
191005


Finishes: CH, ORB, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Brantford (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 7185
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Handsfree Motionsense Faucet 7185E
    • Wand Numbers 179645, 153977, 161157 and 191005
  • Hands Free Wave Faucet 7185EW
    • Never Used 191005
    • Wand Number Used 140246
191006


Finishes: CH, ORB, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Notch 9124

  • Sold through wholesale and plumbing distributors
  • Wand Numbers 175984 and 191006
193876


Finishes: SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.73" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Morado 87394

  • Sold in retail stores
  • Wand Number 193876

Surie 87395

  • Sold in retail stores
  • Wand Number 193876
194878


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 1.73" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Sarai 87836

  • Sold in retail stores
  • Wand Number 194878

Sinema-(Sold through wholesale and plumbing distributors)

  • Smart Faucet S7235EV2
195357


Finishes: CH, SRS, BL

Features:

  • 1.5 GPM
  • Metal
  • 3.68" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Paterson (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet S72003
    • Wand Number 195357
  • Mechanical Spring Faucet S72103
    • Wand Number 195357
  • Smart Faucet S72003EV
    • Wand Number 195357
  • Bar Faucet S52003
    • Never Used 195357
    • Wand Number Used 195360
195360


Finishes: CH, BL, SRS

Features:

  • 1.5 GPM
  • Metal
  • " Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

118298 pad.png

Model Name/Model Number/Spray Wands Used:

Paterson (Sold through wholesale and plumbing distributors)

  • Bar Faucet S52003
    • Wand Number 195360
  • Mechanical Faucet S72003
    • Never Used 195360
    • Wand Number Used 195357
  • Mechanical Spring Faucet S72103
    • Never Used 195360
    • Wand Number Used 195357
  • Smart Faucet S72003EV
    • Never Used 195360
    • Wand Number Used 195357
195370


Finishes: CH, SRS, NL, BG, ORB

Features:

  • 1.5 GPM
  • Metal
  • 3.68" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Weymouth (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet S73004
    • Wand Number 195370
  • Mechanical Spring Faucet S73104
    • Wand Number 195370
  • Smart Faucet S73004EV
    • Wand Number 195370
  • Bar Faucet S53004
    • Never Used 195370
    • Wand Number Used 195383
195383


Finishes: CH, SRS, ORB, BG, NL

Features:

  • 1.5 GPM
  • Metal
  • 2.28" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

118298 pad.png

Model Name/Model Number/Spray Wands Used:

Weymouth (Sold through wholesale and plumbing distributors)

  • Bar Faucet S53004
    • Wand Number 195383
  • Mechanical Faucet S73004
    • Never Used 195383
    • Wand Number Used 195370
  • Mechanical Spring Faucet S73104
    • Never Used 195383
    • Wand Number Used 195370
  • Smart Faucet S73004EV
    • Never Used 195383
    • Wand Number Used 195370
196227


Finishes: CH, SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

100499 pad.png

Attachments:

  • Includes 3 attachments: Targeted Spray, Four-Corner Spray And Broom Spray

Model Name/Model Number/Spray Wands Used:

Venango 87113

  • Sold in retail stores
  • Wand Number 196227
196230


Finishes: CH, SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  •  Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

100499 pad.png

Attachments:

  • Includes 3 attachments: Targeted Spray, Four-Corner Spray And Broom Spray

Model Name/Model Number/Spray Wands Used:

Milton 87114

  • Sold in retail stores
  • Wand Number 196230
198279


Finishes: CH, SRS, BL, BLS, BG, ORB

Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Sleek (Sold through wholesale and plumbing distributors)

Cadia 87869

  • Sold in retail stores
  • Wand Number 198279
  • Mechanical Faucet 7864
    • Wand Numbers 187728 and 198279
  • Mechanical Spring Faucet 5925
    • Wand Number 198279
  • Smart Faucet 7864EV
    • Wand Number 198279
  • Hands Free Wave Faucet 7864EW
    • Never Used 198279
    • Wand Number Used 187728
  • Bar Faucet 7664
    • Never Used 198279
    • Wand Number Used 198921
198280


Finishes: CH, SRS, BL



Features:

  • 1.5 GPM
  • Plastic
  • 3.24" Long
  • 2 Button/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Buttons/Pads:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Tullis 5926

  • (Sold through wholesale and plumbing distributors)
  • Wand Number 198280
198297


Finishes: CH, SRS, BRB

Features:

  • 1.5 GPM
  • Plastic
  • 2.71" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Plastic)

168500 pad.png

Model Name/Model Number/Spray Wands Used:

Adler (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet 87233
    • Sold through wholesale and plumbing distributors
    • Wand Number 198297
  • Hands Free Wave Faucet 87233EW
    • Sold through wholesale and plumbing distributors
    • Wand Number 198297
198921


Finishes: CH, SRS, BL, BLS, ORB, BG

Features:

  • 1.5 GPM
  • Plastic
  • 2.3" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

168949 pad.png

Model Name/Model Number/Spray Wands Used:

Sleek (Sold through wholesale and plumbing distributors)

  • Bar Faucet 7664
    • Wand Number 198921
  • Mechanical Faucet 7864
    • Never Used 198921
    • Wand Numbers Used 187728 and 198279
  • Mechanical Spring Faucet 5925
    • Never Used 198921
    • Wand Number Used 198279
  • Smart Faucet 7864EV
    • Never Used 198921
    • Wand Number Used 198279
  • Hands Free Wave Faucet 7864EW
    • Never Used 198921
    • Wand Number Used 187728
199158


Finishes: CH, SRS, BL, NL

Features:

  •  GPM
  • Metal
  • 2.48" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

168949 pad.png

Model Name/Model Number/Spray Wands Used:

Sinema (Sold through wholesale and plumbing distributors)

  • Bar Faucet S6235
    • Wand Number 199158
  • Mechanical Faucet S7235
    • Never Used 199158
    • Wand Number Used 199164
  • Mechanical Spring Faucet S5235
    • Never Used 199158
    • Wand Number Used 199164
199164


Finishes: CH, SRS, BL, NL

Features:

  • 1.5 GPM
  • Metal
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Sinema (Sold through wholesale and plumbing distributors)

  • Mechanical Faucet S7235
    • Wand Number 199164
  • Mechanical Spring Faucet S5235
    • Wand Number 199164
  • Bar Faucet S6235
    • Never Used 199164
    • Wand Number Used 199158
199817


Finishes: CH, BN, SRS

Features:

  • 1.0 GPM
  • Metal
  • 1 Buttons/Pads
  • 2 Spray Functions: Stream and Spray

Button/Pad:

(Rubber)

100499 pad.png

Model Name/Model Number/Spray Wands Used:

Cleveland Faucet Group

Slate 76162

  • Sold through wholesale and plumbing distributors
  • Wand Number 162716 & 199817
201994


Finishes: CH, BG, BL, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 2 Buttons/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:


Model Name/Model Number/Spray Wands Used:

Cia 7622

  • Sold through wholesale and plumbing distributors
  • Wand Number 201994
203824


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 2 Buttons/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:


Model Name/Model Number/Spray Wands Used:

Boman 87162

  • Sold in retail stores
  • Wand Number 203824
204216


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 2 Buttons/Pad
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:


Model Name/Model Number/Spray Wands Used:

Swinden 87922

  • Sold in retail stores
  • Wand Number 204216
204218


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Sabelton 87161

  • Sold in retail stores
  • Wand Number 204218
204775


Finishes: CH, BL, NL, SRS

Features:

  • 1.5 GPM
  • Metal
  • 3.24" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Kurv 9126

  • Sold through wholesale and plumbing distributors
  • Wand Number 204775
204776


Finishes: CH, BL, NL, SRS

Features:

  • 1.5 GPM
  • Metal
  • 3.24" Long
  • 1 Button/Pad
  • 2 Spray Functions: Stream, Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Hands Free Wave Faucet Kurv 9126EW

  • Sold through wholesale and plumbing distributors
  • Wand Number 204776
204777


Finishes: CH, BL, NL, SRS

Features:

  • 1.5 GPM
  • Metal
  • 1 Button/Pad
  • 2.18" Long
  • 2 Spray Functions: Stream, Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up

Button/Pad:

(Rubber)

151189 pad.png

Model Name/Model Number/Spray Wands Used:

Bar Faucet Kurv 6126

  • Sold through wholesale and plumbing distributors
  • Wand Number 204777
205846


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Belfield (Sold through wholesale and plumbing distributors)

Mechanical Faucets 7260

Mechanical Spring Faucet 5927

  • Wand Number 205846
205860


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Fenn 87163

  • Sold in retail stores
  • Wand Number 205860
210118


Finishes: CH, BL, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.74" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Power Clean Spray*

*Power Clean: Provides a powerfully concentrated spray for faster clean up



Button/Pad:

100499 pad.png

Model Name/Model Number/Spray Wands Used:

Haelyn (Sold in retail stores)

 Hands Free Wave Faucet 87627EW

  • Wand Number 210118
210944


Finishes: CH, BL, BZG, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)




Model Name/Model Number/Spray Wands Used:

Meena 87270

  • Sold in retail stores
  • Wand Number 210944
210947


Finishes: SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

  • *Power Boost: Provides boosted water performance with the push of a button

Buttons/Pads:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Eligia 87982

  • Sold in retail stores
  • Wand Number 210947
212613

clipboard_e3362601fba8924bd7e9745e19a49a6d7.pngFinishes: CH, BL, BZG, SRS

Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)


Model Name/Model Number/Spray Wands Used:

Rayes 87932

  • Sold in retail stores
  • Wand Number 212613
212676

162716 wand.png

Finishes: CH, BL, SRS

Features:

  • 1.0 GPM
  • Plastic
  • 3.78" Long
  • 1 Button/Pad
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

(Rubber)

162716 pad.png

Model Name/Model Number/Spray Wands Used:

Cleveland Faucet Group

Slate 76160

  • Sold through wholesale and plumbing distributors
  • Wand Number 212676
212677

175392 wand.png

Finishes: CH, CSL

Features:

  • 1.0 GPM
  • Plastic
  • 3.35" Long
  • 0 Buttons/Pads
  • 2 Sprayer Functions: Stream and Spray

Button/Pad:

None- Face of spray wand rotates to change functions

175392 pad.png

Model Name/Model Number/Spray Wands Used:

Cleveland Faucet Group Edgestone 46200

  • Sold through wholesale and plumbing distributors
  • Wand Number 212677
212866


Finishes: CH, BL, BZG, SRS



Features:

  • 1.5 GPM
  • Plastic
  • 3.25" Long
  • 2 Buttons/Pads
  • 4 Spray Functions: Stream, Spray, Power Boosted Stream And Spray*

*Power Boost: Provides boosted water performance with the push of a button

Button/Pad:

(Rubber)






Model Name/Model Number/Spray Wands Used:

Nolia 87886

  • Sold in retail stores
  • Wand Number 212866

For warranty information, see article How to Identify if My Product is Warrantied.

For additional information on Moen products visit solutions.moen.com and select the type of product you are repairing. The guide will contain repair details, troubleshooting and specific information on assembling handles associated with that style of product.

Still Not Finding What You're Looking For?

Contact Us or Call 1-800-BUY-MOEN

Non US?  Moen Canada | Other International Sites

  1. Back to top
  • Was this article helpful?

Recommended articles

  1. Article type
    Topic
  2. Tags
    1. Topic-How To Identify A Moen Product
